LTE-Advanced cat6 supported with up to 300Mbps download and 50Mbps upload speeds Supports up to 32 devices simultaneously Selectable 300Mbps at 2.4GHz or 867Mbps at 5GHz dual band Wi-Fi All useful information at a glance with screen display 3000mAh battery for up to 15 hours of working Equipped with a micro SD card slot for up to 32GB of optional storage Easy management with the tpMiFi App
HARDWARE FEATURES Interface 1 micro USB port for power supply 1 Micro SIM card slot 1 Micro SD card slot Button Power On/Off，Menu Power Supply 3000mAh Rechargeable Battery Antenna Internal Antenna Network Type FDD-LTE: B1/B3/B7/B8/B20(2100/1800/2600/900/800MHz) TDD-LTE: B38/B40/B41 (2600/2300/2500MHz) DC-HSPA+/HSPA/UMTS: B1/B8(2100/900MHz) EDGE/GPRS/GSM: 850/900/1800/1900MHz Data Rates DL: 300Mbps; UL: 50Mbps Dimensions ( W x D x H ) 112.5*66.5*16mm Micro SD Card Reader Up to 32GB Screen Display 1.44 inch TFT WIRELESS FEATURES Wireless Standards IEEE 802.11a/b/g/n/ac 300Mbps at 2.4GHz or 867Mbps at 5GHz Frequency 2.4GHz&5GHz Transmit Power 2.4G <20dbm; 5G <23dbm Wireless Security Support WPA-PSK/WPA2-PSK; Wireless MAC Filtering; DHCP DHCP server; DHCP Client List OTHERS Certification CE; RoHS Package Contents 300Mbps LTE-Advanced Mobile Wi-Fi M7450 Micro USB Cable Nano to Micro SIM Card Adapter 3000mAh Battery Quick Installation Guide System Requirements Windows 10/8/7/vista/XP; Mac OS; Android; iOS; Windows Phone
@28/30
Warranty Period: 3-Year
@35/34
@88/49
@5/16
Complies with 802.3u 10/100Base-TX; 100Base-FX standards. Link Fault Passthrough and Far End Fault minimize the loss caused by link failure timely Adopts WDM technology; transmitting and receiving data on one single fiber
What This Product Does The MC112CS is a media converter designed to convert 100BASE-FX fiber to 100Base-TX copper media or vice versa. Adopting WDM technology; MC112CS takes only one fiber cable to transmit and receive data; which will save half cabling cost for you. Designed under IEEE 802.3u 10/100Base-TX and 100Base-FX standards; the MC112CS is designed for use with single-mode fiber cable utilizing the SC-Type connector. The MC112CS supports longwave (LX) laser specification at a full wire speed forwarding rate. It works at 1310nm on transferring data and at 1550nm on receiving data. So the other end device to cooperate with the MC112CS should work at 1550nm on transferring data and at 1310nm on receiving data. Another TP-LINK’s media converter MC111CS is just one of the examples to cooperate with MC112CS.
MEDIA CONVERTER & MODULE Standards and Protocols IEEE 802.3; IEEE 802.3u; IEEE 802.3x Basic Function Adopts WDM technology Half/Full-Duplex transfer mode for FX port Full Duplex Flow Control (IEEE 802.3x) Half Duplex Flow Control (Backpressure) Link Fault Passthrough and Far End Fault minimize the loss caused by link failure timely Extends fiber distance up to 20km Ports 1 100M SC/UPC port 1 100M RJ45 port (Auto MDI/MDIX) Wave Length 1310nm Tx/1550nm Rx WDM TX 1310nm WDM RX 1550nm Network Media 10BASE-T UTP category 3; 4; 5 cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m) Network Media 100BASE-T UTP category 5; 5e cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m) Network Media 100BASE-FX Single-mode Fiber LED Indicators PWR; FDX/Col; Link/Act; SPD Power Supply External Power Adapte
@5/15
14 bays to house up to 14 media converters Optional redundant power supply to ensure non-stop reliable operation Hot-Swappable; easy & quick replacement of converter and power supply Mounted two cooling fans for better ventilation
The TL-MC1400 14-slot 19" rack-mount chassis is designed specially to accommodate 14 TP-LINK media converters.
The centralized power supply makes the installation neat and sharp. The hot-swappable redundant power supply (purchase separately) design comes with chases allows uninterrupted installation and maintenance jobs. Two cooling fans are installed to stabilize the performance and extend the lifetime
Together with MC series Gigabit or Fast Ethernet media converters; TL-MC1400 is the ideal solution for your media conversion network.
@33/32
Works at 1000Mbps in Full-Duplex mode for both TX port and FX port Supports auto MDI/MDIX for TX port Provides switch configuration of Force /Auto transfer mode for FX port. Extends fiber distance up to 15km Easy-to-view LED indicators provide status to monitor network activity easily External power supply
What This Product Does The MC210CS is a media converter designed to convert 1000BASE-LX/LH fiber to 1000Base-T copper media or vice versa. Designed under IEEE802.3ab 1000Base-T and IEEE802.3z 1000Base-LX/LH standards; the MC210CS is designed for use with single-mode fiber cable utilizing the SC-Type connector. The MC210CS supports longwave (LX) laser specification at a full wire speed forwarding rate. It works at 1310nm on both transmitting and receiving data.
Other features of this module include the ability to be used as a stand alone device (no chassis required) or with TP-LINK´s 19´´system chassis; Auto MDI/MDI-X for TX port; and front panel status LEDs. The MC210CS will transmit at extended fiber optic distances utilizing single-mode fiber up to 15 kilometers.
MEDIA CONVERTER & MODULE Standards and Protocols IEEE 802.3ab; IEEE 802.3z; IEEE 802.3x Basic Function Full Duplex Flow Control (IEEE 802.3x) Extends fiber distance up to 15km Ports 1 1000M SC/UPC port 1 1000M RJ45 port (Auto MDI/MDIX) Wave Length 1310nm Network Media 1000BASE-FX Single-mode Fiber Network Media 1000BASE-T UTP category 5; 5e cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m) LED Indicators PWR; LINK; RX Dimensions (W*D*H) 3.7*2.9*1.1 in. (94.5*73.0*27.0 mm) Power Supply External Power Adapter Max Power Consumption 5.5W Safety & Emission FCC; CE; RoHS Environment Operating Temperature: 0℃~40℃ (32℉~104℉) Storage Temperature: -40℃~70℃ (-40℉~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing
@6/16
@5/15
@8/15
Up to 102 watts output power Output over-voltage/short circuit/over-current protection
What this product does The TP-LINK Redundant Power Supply Module TL-MCRP100 is an AC-input and DC-output power supply module. It can convert 100-240V 50/60Hz input voltage into 9.5VDC output with rated wattage of 102W. The power supply module supports output over-voltage/short circuit/over-current protection. TL-MCRP100 is applicable to 14-Slot Rackmount Chassis TL-MC1400.
REDUNDANT POWER SUPPLY AC Power Input 100-240V~ 50/60Hz 3A DC Power Output 9.5V/9.5A Dimensions 210*130*70 mm Environment Operating Temperature: 0℃~60℃ (32℉~140℉) Storage Temperature: -35℃~85℃ (-31℉~185℉) Operating Humidity: 20%~90%RH non-condensing Storage Humidity: 10%~95%RH non-condensing
@14/19
@64/50
Dedicated Network for Centralised Management The OC200 Omada Cloud Controller provides centralised management of the whole Omada network. Monitor statistics in real-time; view a graphical analysis of network traffic; create a captive portal; upgrade and reboot your system; and effortlessly scale your network to boost your business.
Professional centralised management for Wi-Fi network Cloud access to manage from anywhere; anytime PoE (802.3af/802.3at) supported for easy installation Industry-leading hardware design with a powerful chipset; durable metal casing; and USB port for auto backup Omada App for a convenient management Secure guest network with multiple login options(Facebook Wi-Fi; SMS login; Voucher)
HARDWARE FEATURES Interface 10/100Mbps Ethernet Port*2 USB 2.0 Port*1 Micro USB Port*1 Power Supply 802.3af/at PoE or Micro USB（DC 5V/Minimum 1A） Dimensions 3.9×3.9×1.0 in (100×98×25 mm)
FEATURES Wireless Fuction L3 Management Multi-SSID Load Balance Band Steering Airtime Fariness Beamforming Rate Limit Wireless Schedule QoS Wireless Security Captive Portal Authentication Access Control Wireless Mac Address Filtering Wireless Isolation Between Clients SSID to VLAN Mapping Rogue AP Detection AP Management Automatic Discovery Unified Configuration Reboot Schedule Batch Firmware Upgrade LED ON/OFF Authentication Captive Porta
MANAGEMENT Omada App Yes Centralized Management Up to 100 Omada access points; JetStream switches; and SafeStream routers Cloud Access Yes L3 Management Yes Multi-site Management Yes
@18/23
HARDWARE FEATURES Interface • 2× 10/100/1000 Mbps Ethernet Ports • 1× USB 3.0 Port Power Supply 100–240 V~50/60 Hz; 0.6 A Dimensions 11.6 × 7.1 × 1.7 in (294 × 180 × 44 mm) MANAGEMENT Omada App Yes Centralized Management • Up to 500 Omada access points; JetStream switches; and SafeStream routers* • Up to 15;000 clients
*Only some JetStream switches and Safestream gateways can be centrally managed by OC300; please refer to www.tp-link.com/business-networking/all-omada/ to find all the models supported by OC300 Cloud Access Yes L3 Management Yes Multi-site Management Yes Management Features • Automatic Device Discovery • Batch Configuration • Batch Firmware Upgrading • Intelligent Network Monitoring • Abnormal Event Warnings • Unified Configuration • Reboot Schedule • Captive Portal Configuration
OTHERS Certification CE; FCC; RoHS Package Contents • Omada Hardware Controller OC300 • Quick Installation Guide • Ethernet Cable • Power Cord • Rackmount Kit System Requirements Microsoft® Windows®10; 8; 7;Vista™; XP or MAC® OS; NetWare®; UNIX® or Linux Environment • Operating Temperature: 0–50 ℃ (32–122 ℉) • Storage Temperature: -40–70 ℃ (-40–158 ℉) • Operating Humidity: 10–90%
@55/45
@0/68
Warranty Period: 3-Year
@3/15
Warranty Period: 3-Year
