HARDWARE FEATURES Standards and Protocols IEEE 802.3 IEEE 802.3u IEEE 802.3ab IEEE 802.3x IEEE 802.3af IEEE 802.3at IEEE 802.1q IEEE 802.1p Interface 16 PoE+ 10/100/1000Mbps RJ45 Ports 2 Fiber Ports Network Media 10BASE-T: UTP category 3 4 5 cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m) 100BASE-TX: UTP category 5 5e cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m) 1000BASE-T: UTP category 5 5e 6 or above cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m) 1000BASE-X MMF SMF Fan Quantity 2 Fans Physical Security Lock Yes Power Supply 100-240V AC 50/60 Hz Backup Bandwidth 7.2 Gbps PoE+ Ports(RJ45) Standard: 802.3at/802.3af compliant PoE Ports: Port1- Port16 PoE Power Budget: 192W Mac Address Table 8K Dimensions ( W x D x H ) 17.3 × 7.1 × 1.7 in. (440 × 180 × 44 mm) Mounting Rack Mountable Max Power Consumption 18.73 W (220/50Hz. no PD connected) 217.22 W (220/50Hz. with 192W PD connected) Max Heat Dissipation 63.89 BTU/h (no PD connected) 741.15 BTU/h (with 192W PD connected)
PERFORMANCE Switching Capacity 36 Gbps Packet Forwarding Rate 23.8 Mbps MAC Address Table 8K Packet Buffer Memory 4.1 Mbit Jumbo Frame 9 KB
@64
TP-Link TL-SG1428PE 28-Port Gigabit Easy Smart Switch with 24-Port PoE+
* 24 10/100/1000Mbps RJ45 PoE+ Ports Switch with 2 SFP Slots * PoE power budget is up to 250 W* making it ideal for small to medium business surveillance systems * Priority Mode helps to guarantee the quality of sensitive application like video monitoring * PoE Auto Recovery enables system self-healing to guarantee the stable operation of PoE-connected devices * QoS is for smooth internet-surfing experience and IGMP Snooping is capable of optimizing traffic for IPTV * Intelligent power management can protect the switch from overload
HARDWARE FEATURES Standards and Protocols IEEE 802.3 IEEE 802.3u IEEE 802.3ab IEEE 802.3x IEEE 802.3af IEEE 802.3at IEEE 802.1q IEEE 802.1p Interface 26 10/100/1000 Mbps RJ45 Ports 2 Gigabit SFP Ports Network Media 10BASE-T: UTP category 3 4 5 cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m) 100BASE-TX: UTP category 5 5e cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m) 1000BASE-T: UTP category 5 5e 6 or above cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m) 1000BASE-X MMF SMF Fan Quantity 2 Fans Physical Security Lock Yes Power Supply 100-240V AC 50/60 Hz PoE+ Ports(RJ45) Standard: 802.3at/802.3af compliant PoE+ Ports: 24 Ports Power Supply: 250 W Dimensions ( W x D x H ) 17.3 × 8.7 × 1.73 in (440 × 220 × 44 mm) Mounting Rack Mountable Max Power Consumption 27 W (220/50Hz. no PD connected) 304.7 W (220/50Hz. with 250 W PD connected) Max Heat Dissipation 92.07 BTU/h (no PD connected) 1039.03 BTU/h (with 250 W PD connected)
PERFORMANCE Switching Capacity 56 Gbps Packet Forwarding Rate 41.7 Mbps MAC Address Table 8K Packet Buffer Memory 4.1 Mbit Jumbo Frame 9 KB
SOFTWARE FEATURES Quality of Service Support Port-based 802.1p/DSCP priority
@81
HARDWARE FEATURES Interface * 16× PoE+ 10/100 Mbps RJ45 Ports * 2× 10/100/1000 Mbps RJ45 Ports * 1× Combo Gigabit SFP Slot Network Media * 10BASE-T: UTP category 3 4 5 cable (maximum 100m) * EIA/TIA-568 100Ω STP (maximum 100m) * 100BASE-TX: UTP category 5 5e cable (maximum 100m) * EIA/TIA-568 100Ω STP (maximum 100m) * 1000BASE-T: UTP category 5 5e 6 or above cable (maximum 100m) * EIA/TIA-568 100Ω STP (maximum 100m) * 1000BASE-X MMF SMF Fan Quantity 2 Fans Physical Security Lock Yes Power Supply 100–240V AC 50/60 Hz PoE+ Ports(RJ45) * Standard: 802.3at/802.3af compliant * PoE Ports: Ports 1–16 * PoE Power Budget: 150 W Dimensions ( W x D x H ) 17.3 × 7.1 × 1.7 in (440 × 180 × 44 mm) Max Power Consumption * 12.71 W (220/50Hz. no PD connected) * 172.8 W (220/50Hz. with 150 W PD connected) Max Heat Dissipation * 43.34 BTU/h (no PD connected) * 589.25 BTU/h (with 150 W PD connected)
PERFORMANCE Switching Capacity 7.2 Gbps Packet Forwarding Rate 5.36 Mpps MAC Address Table 8K Jumbo Frame 10 KB
SOFTWARE FEATURES Advanced Features * Compatible With IEEE 802.3at/af Compliant PDs * Extend Mode (Up to 250m PoE power supply and data transmission) * Priority Mode * Isolation Mode * Mac Address Auto-Learning And Auto-Aging * IEEE802.3x Flow Control Transmission Method Store-And-Forward
@66/57
HARDWARE FEATURES Interface 24× PoE+ 10/100 Mbps RJ45 Ports 2× 10/100/1000 Mbps RJ45 Ports 2× Combo Gigabit SFP Slots Network Media 10BASE-T: UTP category 3 4 5 cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m) 100BASE-TX: UTP category 5 5e cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m) 1000BASE-T: UTP category 5 5e 6 or above cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m) 1000BASE-X MMF SMF Fan Quantity 2 Fans Physical Security Lock Yes Power Supply 100-240 VAC 50/60 Hz Backup Bandwidth 8.8 Gbps PoE+ Ports(RJ45) Standard: 802.3at/802.3af compliant PoE Ports: Port 1 – Port 24 PoE Power Budget: 250 W Mac Address Table 8 K Dimensions ( W x D x H ) 17.3 × 7.1 × 1.7 in (440 × 180 × 44 mm) Max Power Consumption 18.32 W (220/50 Hz. no PD connected) 294 W (220/50 Hz. with 250 W PD connected) Max Heat Dissipation 62.47 BTU/h (no PD connected) 1002.54 BTU/h (with 250 W PD connected)
SOFTWARE FEATURES Advanced Features Compatible With IEEE 802.3at/af Compliant PDs Extend Mode (Up to 250m PoE power supply and data transmission) Priority Mode Isolation Mode PD Detection Intelligent Power Supply Mac Address Auto-Learning and Auto-Aging IEEE802.3x Flow Control
@65
@24/19
* Support 1000BASE-T Operation in Host Systems * Support TX Disable function * For 100m Reach Over UTP Cat 5e or above Cable * Hot-Pluggable SFP Footprint Features * Commercial Product Operating Temperature Range: 0-70°C * Compliant with IEEE Std 802.3-2002 * Fully Metallic Enclosure for Low EMI * Low Power Dissipation (0.5 W Typical 0.8 W Max)
PACKAGE CONTENTS Package Contents * 1000BASE-T RJ45 SFP Module TL-SM331T * Installation Guide
HARDWARE FEATURES Hot Swappable Yes
TRANSCEIVER Standards and Protocols IEEE 802.3-2002 Power Supply 3.3V Max. Cable Length 100m (Cat 5e or above) Data Rate 1.25 Gbps Port Type 1× 1000 Mbps RJ45 Port Safety & Emission FCC CE Environment Operating Temperature: 0–70 ℃ (32–158 ℉) Storage Temperature: -40–85 ℃ (-40–185 ℉)
@13/26
* Single-mode SFP+ LC Transceiver * Hot-Pluggable with maximum flexibility * Supports Digital Diagnostic Monitoring (DDM) * Compatible with 10G Small Form Pluggable Multi-Source Agreement (SFP+ MSA) * Compatible with switches with 10G SFP+ ports like JetStream TL-SG3428X TL-SG3428XMP and more.
HARDWARE FEATURES DDM Yes SFP-MSA Yes Hot Swappable Yes
TRANSCEIVER Standards and Protocols IEEE 802.3ae TCP/IP Wave Length 1310 nm Power Supply 3.3V Fiber Type 9/125um Single-Mode Max. Cable Length 10 km Data Rate 10 Gbps Port Type LC Duplex Safety & Emission FCC CE Environment Operating Temperature: 0–70 °C (32–158 °F) Storage Temperature: -40–85 °C ( -40–185 °F) Operating Humidity: 10–90% RH Non-Condensing Storage Humidity: 5–90% RH Non-Condensing
Product Width (W) mm 122.5 Product Depth (D) mm 81.5 Product Height (H) mm 38.5 Product Weight Kg 0.06
@16/11
Multi-mode SFP+ LC Transceiver Hot-Pluggable with maximum flexibility Supports Digital Diagnostic Monitoring (DDM) Compatible with 10G Small Form Pluggable Multi-Source Agreement (SFP+ MSA) Compatible with switches with 10G SFP+ ports like JetStream TL-SG3428X TL-SG3428XMP and more.
What This Product Does The TL-SM5110-SR is designed to extend transfer distances based on 10Gbps Ethernet connectivity. It is a 10GBASE-SR high performance 850nm multi-mode SFP+ transceiver. It supports full duplex 10G Ethernet connections up to 300m or 33m with 50/125µm or 62.5/125µm fiber cables respectively.
HARDWARE FEATURES DDM Yes SFP-MSA Yes Hot Swappable Yes TRANSCEIVER Standards and Protocols IEEE 802.3ae TCP/IP SFF-8472 Wave Length 850nm Power Supply 3.3V Fiber Type 50/125um or 62.5/125um Multi-mode Max. Cable Length 300m (OM3) Data Rate 10Gbps Port Type LC/UPC Safety & Emission FCC CE Environment Operating Temperature: 0–70 ℃ (32–158 ℉) Storage Temperature: -40–80 ℃ (-40–176 ℉) Operating Humidity: 10–90% RH non-condensing Storage Humidity: 5–90% RH non-condensing
@12/8
SFP+ CABLE Environment Operating Temperature: 0–70 ℃ (32–158 ℉) Storage Temperature: -40–80 ℃ (-40–176 ℉) Operating Humidity: 10–90% RH non-condensing Storage Humidity: 5–90% RH non-condensing Data Rate 10 Gbps Cable Length 1 m
@12/8
* Support 10GBASE-T 5GBASE-T 2.5GBASE-T 1000BASE-T and 100BASE-TX * Transmit data up to 30m* at 10 Gbps (UTP cat.6a or above) * Support DDM (Temperature and Voltage) * Hot-Pluggable SFP+ Footprint Features * Support TX Disable function * Commercial Product Operating Temperature Range: 0-70°C * Fully Metallic Enclosure for Low EMI
PACKAGE CONTENTS Package Contents * 10G BASE-T RJ45 SFP+ Module TL-SM5310-T * Installation Guide
HARDWARE FEATURES Hot Swappable Yes
TRANSCEIVER Standards and Protocols IEEE Std 802.3 802.3ab 802.3bz 82.3an Power Supply 3.3V Max. Cable Length 100BASE-TX: UTP cat .5 or above (max. 100m) 1000BASE-T/2.5GBASE-T/5GBASE-T: UTP cat.5e or above (max. 100m) 10GBASE-T: UTP cat.6a or above (max. 30m) Data Rate 10.3 Gbps Port Type 1× 10G RJ45 Port Safety & Emission FCC CE RoHS Environment Operating Temperature: 0–70 ℃ (32–158 ℉) Storage Temperature: -40–85 ℃ (-40–185 ℉)
@20/15
TL-SX1008 8-Port 10G Desktop/Rackmount Switch Eight 10 Gbps Ports. 8× 10-Gigabit ports unlock the highest performance of your 10G/Multi-Gig bandwidth and devices and provide up to 160 Gbps of switching capacity. Lightning-Fast Connections. Provides lightning-fast connections to 10G NAS Server 10G PCIe Adapter/ NIC gaming computer 2.5G/5G/10G WiFi 6 AP 8K video and more. Ideal for Various Scenarios. Built for lightning-fast connections in business and home offices workstations LAN parties and home entert
HARDWARE FEATURES Standards and Protocols IEEE 802.3 802.3u 802.3ab 802.3x 802.1p 802.3an 802.3bz Interface 8× 100Mbps/1Gbps/2.5Gbps/5Gbps/10Gbps Ports Auto-Negotiation Auto-MDI/MDIX Fan Quantity 1 (Intelligent fan speed adjustment) External Power Supply 100–240 VAC 50/60 Hz 0.8A LED Indicator * System Power: 1 * Link/Act Indicators: 8 1 indicator per port built into each RJ-45 port Dimensions ( W x D x H ) 11.6×7.1×1.7 in (294×180×44 mm) Max Power Consumption 31.2 W PERFORMANCE Switching Capacity 160 Gbps Packet Forwarding Rate 119.0 Mpps MAC Address Table 32 K Packet Buffer Memory 2 Mb Jumbo Frame 10 KB SOFTWARE FEATURES Advanced Features * 802.3X Flow Control * 802.1p/DSCP QoS Transfer Method Store and Forward OTHERS Certification CE FCC RoHS Package Contents * 8-Port 10G Multi-Gigabit Desktop/Rackmount Switch TL-SX1008 * Power Cord * Installation Guide * Rackmount Kit * Rubber Feet Environment * Operating Temperature: 0–50 °C (32–122 °F) * Storage Temperature: -40–70 °C (-40–158 °F) * Operating Humidity: 10–90% RH non-condensing * Storage Humidity: 5–90% RH non-condensing
@105
5-Port 10G Desktop Switch Five 10 Gbps Ports. 5× 10-Gigabit ports unlock the highest performance of your 10G/Multi-Gig bandwidth and devices and provide up to 100 Gbps of switching capacity. Lightning-Fast Connections. Provides lightning-fast connections to 10G NAS Server 10G PCIe Adapter/ NIC gaming computer 2.5G/5G/10G WiFi 6 AP 8K video and more. Ideal for Various Scenarios. Built for lightning-fast connections in LAN parties home entertainment small and home offices and workstations. Optimal 5-Speed Connections. Auto-negotiation for 5-speed (100Mbps/1G/2.5G/5G/10G) connections provide optimal performance. Silent Operation. The revolutionary fanless design ensures unprecedented silent operation ideal for any home or business. Durable Metal Casing. Durable metal casing desktop/wall-mounting and professional heat dissipation design are well suited for different environments. Plug and Play. Allows for easy deployment without the need for a technician.
HARDWARE FEATURES Standards and Protocols IEEE 802.3 802.3u 802.3ab 802.3x 802.1p 802.3an 802.3bz Interface 5× 100Mbps/1Gbps/2.5Gbps/5Gbps/10Gbps Ports Auto-Negotiation Auto-MDI/MDIX Fan Quantity Fanless External Power Supply External Power Adapter (Output: 12 VDC / 2.0 A) LED Indicator * System Power: 1 * Link/Act Indicators: 5 1 indicator per port built into each RJ-45 port Dimensions ( W x D x H ) 8.9×5.2×1.4 in (226×131×35 mm) Max Power Consumption 21.4 W PERFORMANCE Switching Capacity 100 Gbps Packet Forwarding Rate 74.4 Mpps MAC Address Table 32 K Packet Buffer Memory 2 Mb Jumbo Frame 10 KB SOFTWARE FEATURES Advanced Features * 802.3X Flow Control * 802.1p/DSCP QoS Transfer Method Store and Forward OTHERS Certification CE FCC RoHS Package Contents * 5-Port 10G Multi-Gigabit Desktop/Rackmount Switch TL-SX105 * Power Cord * Install
@89
HARDWARE FEATURES Interface 1× 10/100/1000 Mbps Ethernet Port (Supports Passive PoE) Button Power On/Off Button WPS Button Reset Button External Power Supply 12V/1.5A Wireless Standards IEEE802.11b/g/n 2.4 GHz IEEE 802.11ac/n/a 5 GHz Dimensions ( W x D x H ) 225×145.5×37 in (400×255×72 mm) Antenna Type 4 Fixed High Performance Antennas WIRELESS FEATURES Frequency 2.4 GHz and 5 GHz Signal Rate 867 Mbps at 5 GHz 300 Mbps at 2.4 GHz Reception Sensitivity 5 GHz: 11a 6 Mbps: -95 dBm 11a 54 Mbps: -81 dBm 11ac VHT20(MCS0): -94 dBm 11ac VHT20(MCS8): -71 dBm 11n HT40(MCS0): -91 dBm 11n HT40(MCS7): -71 dBm 11ac VHT80(MCS0): -88 dBm 11ac VHT80(MCS9): -63 dBm
2.4 GHz: 11g 54Mbps: -78 dBm 11n HT20(MCS0): -92 dBm 11n HT20(MCS7): -74 dBm 11n HT40(MCS0): -88 dBm 11n HT40(MCS7): -72 dBm Transmit Power CE: <20dBm(2.4GHz) <23dBm(5.15GHz~5.25GHz) FCC: <30dBm(2.4GHz&5GHz) Wireless Modes Access Point Range Extender Client Multi-SSID Wireless Functions Enable/Disable Wireless Radio WDS Bridge WMM Wireless Statistics Wireless Multicast Forwarding DHCP Server Access Control Wireless Security 64/128-bit WEP WPA/WPA2 WPA-PSK/WPA-PSK2 encryptions DHCP Server DHCP Client List Quality of Service WMM Advanced Functions Captive Portal OTHERS Certification CE FCC RoHS Package Contents Wireless Access
@21/17
@33/26
Warranty Period: 3-Year
@44/37
HARDWARE FEATURES Interface 1× 10/100 M Ethernet Port(RJ45) Support Passive PoE Button Power On/Off Button WPS Button Reset Button External Power Supply 9VDC / 0.6A Wireless Standards IEEE 802.11n IEEE 802.11g IEEE 802.11b Dimensions ( W x D x H ) 7.1 × 5.1 × 1.4 in (181.6 × 129.5 × 36.2 mm) Antenna Type 2 Fixed Omni-Directional Antennas WIRELESS FEATURES Frequency 2.4 GHz Signal Rate 300 Mbps at 2.4 GHz Reception Sensitivity 11g 6Mbps: -90dBm 11g 54Mbps: -77dBm 11n HT20 MC7: -73dBm 11n HT40 MC7: -70dBm Transmit Power CE: <15dBm; FCC: <20dBm Wireless Modes AP Mode Multi-SSID Mode Client Mode Range Extender Mode Wireless Functions Enable/Disable Wireless Radio WMM Short GI AP Isolation Wireless Statistics Throughput Monitor Wireless Security WEP WPA/WPA2 WPA/WPA2-PSK encryptions Quality of Service WMM Management SNMP Advanced Functions Up to 30 meters Passive PoE is supported OTHERS Certification CE FCC RoHS Package Contents Wireless Access Point TL-WA801N Power Adapter Passive PoE Power Injector RJ45 Ethernet Cable Quick Installation Guide System Requirements Microsoft Windows 98SE/NT/2000/XP/Vista™/7/8/8.1/10 MAC OS NetWare UNIX or Linux Internet Explorer 11 Firefox 12.0 Chrome 20.0 Safari 4.0 or other Java-enabled browser Cable or DSL Modem Subscription with an Internet Service Provider (for Internet access) Environment Operating Temperature: 0°C~40°C (32°F ~104°F) Storage Temperature: -40°C~70°C (-40°F ~158°F) Operating Humidity: 10%~90% RH Storage Humidity: 5%~90
@14/10
Range Extender mode boosts wireless signal to previously unreachable or hard-to-wire areas flawlessly Miniature size and wall-mounted design make it easy to deploy and move flexibly Easily expand wireless coverage at a push of Range Extender button Ethernet port allows the Extender to function as a wireless adapter to connect wired devices
HARDWARE FEATURES Plug Type EU UK US Interface 1 * 10/100M Ethernet Port (RJ45) Button RE (Range Extender) Button Reset Button Power Consumption About 3W Antenna 2 * internal Wireless Standards IEEE 802.11n IEEE 802.11g IEEE 802.11b Dimensions ( W x D x H ) 4.3x 2.6 x 3.0in. (110.0 x 65.8 x 75.2mm) WIRELESS FEATURES Frequency 2.4~2.4835GHz Signal Rate 11n: Up to 300Mbps (dynamic) 11g: Up to 54Mbps (dynamic) 11b: Up to 11Mbps (dynamic) Reception Sensitivity 270M: -68dBm@10% PER 130M: -68dBm@10% PER 108M: -68dBm@10% PER 54M: -68dBm@10% PER 11M: -85dBm@8% PER 6M: -88dBm@10% PER 1M: -90dBm@8% PER Transmit Power < 20 dBm (EIRP) Wireless Modes Range Extender Wireless Functions WMM (Wi-Fi Multimedia) Wireless MAC Address Filtering Wireless Statistic Domain Login Function Wireless Security 64/128/152-bit WEP WPA-PSK / WPA2-PSK OTHERS Certification CE RoHS Package Contents 300Mbps Universal Wi-Fi Range Extender TL-WA850RE RJ-45 Ethernet Cable Resource CD Quick Installation Guide System Requirements Microsoft® Windows® 98SE NT 2000 XP Vista or Windows 7 8 10 Mac® OS NetWare® UNIX® or Linux. Environment Operating Temperature: 0°C~40°C (32°F~104°F) Storage Temperature: -40°C~70°C (-40°F~158°F) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing
@14/26
Boosts your existing Wi-Fi coverage to deliver fast and reliable wired and wireless connectivity External antennas for faster and more reliable Wi-Fi Supports AP mode which creates a new Wi-Fi Access point Easily expand wireless coverage at a push of the Range Extender button Set the Power Schedule for the range extender for power-saving Tether App allows easy access and management with your mobile devices remotely Works with Any Wi-Fi Router
HARDWARE FEATURES Plug Type AU Interface 1 x 10/100M Ethernet Port (RJ45) Button WPS Button Reset Button Power Consumption 3.6W Antenna 2 x external Dimensions ( W x D x H ) 3.15 x 3.06 x 3.04 in. (80 x 77.8 x 77.3mm) WIRELESS FEATURES Wireless Standards IEEE 802.11n IEEE 802.11g IEEE 802.11b Frequency 2.4~2.4835GHz Signal Rate 11n: Up to 300Mbps (dynamic) 11g: Up to 54Mbps (dynamic) 11b: Up to 11Mbps (dynamic) Reception Sensitivity 270M: <-68dBm@10% PER 130M: <-68dBm@10% PER 108M: <-68dBm@10% PER 54M: <-68dBm@10% PER 11M: <-68dBm@8% PER 6M: <-68dBm@10% PER 1M: <-68dBm@8% PER Transmit Power < 20 dBm (EIRP) Wireless Modes Range Extender/Access Point Wireless Functions Wireless MAC Address Filtering Domain Login Function Transmit Power Control Wireless Security 64/128/152-bit WEP WPA-PSK / WPA2-PSK OTHERS Certification CE RoHS Package Contents 300Mbps Wi-Fi Range Extender TL-WA855RE Quick Installation Guide System Requirements Microsoft® Windows® 98SE NT 2000 XP Vista or Windows 7 8 8.1 10 Mac® OS NetWare® UNIX® or Linux. Environment Operating Temperature: 0°C~40°C (32°F~104°F) Storage Temperature: -40°C~70°C (-40°F~158°F) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing
@12/8
