The Pulse Larsen 4G Magnetic Antenna 698 to 2700 MHz SMA Male offers a sleek compact design ideal for a range of applications. With a robust build and a stylish black radome made of PC + ABS plastic this antenna is perfect for mounting on vehicles or enclosures where space is limited but performance is crucial.
Key Features:
- 5G Ready*
- 4.5dB gain for 698-960 MHz
- 5.6dB gain for 1710-2400 MHz
- 4dB gain for 2500-2700 MHz
* 5G via Dynamic Spectrum Sharing (DSS) on compatible repeaters including the CEL-FI R41.
Note: Antenna base needs to be placed on a metal ground plane.
Specification:
| Category | Specification | Details |
|---|---|---|
| Model | Pulse Part Number | SLPT698/2170NMOHF + NMOMMRDSSMA |
| Frequency Range | Frequency | 698-960 MHz 1710-2400 MHz 2500-2700 MHz |
| Nominal Impedance | Impedance | 50 Ω |
| Gain | Average Gain | 4.5 dBi 5.6 dBi 4 dBi across frequency bands |
| VSWR | Return Loss | 3.0:1 2.0:1 2.2:1 across frequency bands |
| Polarisation | Orientation | Vertical |
| Radiation Pattern | Pattern Type | Omni Horizontal Plane |
| Power Rating | Maximum Power | 10 W |
| Material | Radome Material | PC + ABS Plastic |
| Colour | Appearance | Black |
| Ingress Protection | Protection Rating | IP-67 |
| Dimensions | Size | 76.2 mm Ø base x 38.1 mm height |
| Weight | Net Weight | 70.87 g |
| Operating Temperature | Temperature Range | -40 °C to +85 °C |
| Storage Temperature | Temperature Range | -40 °C to +85 °C |
| Relative Humidity | Humidity | 100% |
| Mounting | Mount Type | NMOHF Mount |
@14/29
Description::
The Pulse Larsen 4G Ultrathin White DAS Antenna 698 to 2700 MHz N Female is a cutting-edge ultrathin antenna designed for in-building Distributed Antenna Systems (DAS). Featuring a sleek white radome this antenna is ideal for applications where aesthetic considerations are paramount. Its compact design allows for discreet installation seamlessly blending into modern environments.
Key Features:
- Ultra-Thin Design
- White Radome
- 608 MHz to 2700 MHz Broad Frequency Coverage
- High PIM Rating
- Available with N Female Mini-DIN and 4.3-10 DIN female connectors.
- RoHS Compliant
- High Efficiency
High Performance Across Multiple Bands
With a frequency range spanning from 608 to 2700 MHz the DASUTWC500NF delivers exceptional performance across cellular and Wi-Fi bands. The antenna boasts impressive average peak gains of up to 7 dBi and maintains high efficiency levels ensuring reliable signal reception and transmission across various frequencies.
Exceptional PIM Ratings for Optimal Signal Quality
Engineered to meet stringent performance requirements this antenna excels with a Passive Intermodulation (PIM) rating of ≤155 dBc at 2 × 20W. This ensures minimal interference and maintains the integrity of the signal crucial for high-performance DAS systems in complex installations.
Versatile Connectivity Options
The DASUTWC500NF is available with multiple connector options including N Female Mini-DIN and 4.3-10 DIN female connectors. This versatility allows for flexible integration with existing systems and facilitates a range of installation scenarios.
RoHS Compliant and Future-Proof Design
Designed with environmental considerations in mind the DASUTWC500NF is RoHS compliant ensuring it meets international standards for hazardous substances. The patent-pending design reflects Pulse Electronics’ commitment to innovation and future-proofing their product offerings.
Robust Electrical Specifications
The antenna is engineered to handle a maximum power input of 40W and comes equipped with a 500 mm low-loss cable that is plenum rated. Its VSWR is maintained at 2:1 across the operational frequency bands guaranteeing efficient signal transmission and minimal signal loss.
Specification:
| Category | Specification | Details |
|---|---|---|
| Model Version | DASUTWC500NF | Pulse Larsen 4G Ultrathin White DAS Antenna |
| Description | Radome | Ultrathin white radome for i-DAS |
| Frequency Range | Operating Frequency | 608-960 MHz 1695-2200 MHz 2300-2700 MHz |
| Nominal Impedance | Impedance | 50 Ω |
| VSWR | 698-960 MHz | 2:1 |
| 1695-2700 MHz | 2:1 | |
| Average Peak Gain | 608-960 MHz | 4 dBi |
| 1695-2200 MHz | 6 dBi | |
| 2300-2700 MHz | 6 dBi | |
| Efficiency | 608-960 MHz | 70% |
| 1695-2200 MHz | 65% | |
| 2300-2700 MHz | 60% | |
| Horizontal Plane HPBW | Horizontal Plane | Omni |
| Vertical Plane HPBW | 608-960 MHz | 100° Typ |
| 1695-2200 MHz | 130° Typ | |
| 2300-2700 MHz | 130° Typ | |
| Maximum Power Input | Power Handling | 40 W |
| PIM | At 2 × 20W | ≤ 155 dBc |
| Connector Type | Connector | N Female |
| Cable Type | Type | Dia. 0.4064 cm low loss Low PIM Plenum Rated |
| Cable Length | Length | 500 mm |
| Packaging | Carton | 7 antennas packed in a carton |
| Packaging | Pallet (By Air) | 18 cartons (126 antennas) stack on 1 pallet |
| Packaging | Pallet (By Sea) | 24 cartons (168 antennas) stack on 1 pallet |
@27/51
RFI RFI-3M-SMA 5Mtr RG58 Cable Extension - SMA Male to SMA Female
This RFI-5M-SMA; 5Mtr extension cable is the simplest way to extend the length of your SMA terminated antenna cable to devices that use SMA male connection. (Eg Cel-Fi Go Repeaters)
Cable: RFI RG58 9006 Cellfoil 50 Ohm Coax Cable; Low Loss
Termination: SMA-104 one end SMA-186 other end
Availability
RFI LPDA7038-11-0.5NF 5G LTE 11dBi LPDA Directional Antenna (700-3800 MHz); 0.5MTR HDF195 CABLE N-TYPE (F)
This item is in stock
This wide-band log periodic antenna offers high gain directional coverage and is suited to all global cellular and various other wireless network applications. The unique ruggedized diecast aluminium construction ensures optimum performance and reliability in all weather and operating environments. The LPDA antenna is to be mounted vertically with tilting capability incorporated within the clamping arrangement. Mast mounting hardware is supplied to suite pole diameters of up to 60mm
Pole not included - available to order click here
Features LPDA7038-11-0.5NF:
- Wide band frequency range
- Excellent front-to-back ratio
- Easy installation using supplied hardware
- 0.5Mtrs hdf195 Cable with N conn (F)
The LPDA7038 antenna is to be mounted vertically with tilting capability incorporated within the clamping arrangement. Mast mounting hardware is supplied to suite pole diameters of up to 60mm and includes 0.5 metres of HDF 195 cable terminated with N Type female connector.
Specifications:
| Cable And Connector | 0.5 metres of HDF 195 cable terminated with N Type female connector. |
| Frequency Range | 1710 - 2170 2300 - 2700 3400 - 3800 698 - 960 |
| Frequency | 698-960 / 1710-2700 / 3400-3800 MHz |
| Wind Load (Thrust) @ 160km/h N | 160 |
| Nominal impedance | 50 |
| Power w | 10 |
| Nominal Gain Dbi | 10.8 / 11 / 2.3 |
| Dimensions | 1112 x 200 x 47mm |
| Polarisation | Vertical |
| VSWR | <1.5:1 |
| Tuned bandwidth | Full |
| Horizontal Beamwidth | 55 |
| Front Back ratio dB | 20 dB |
| Brand | RFI |
| Weight [kg] | 1.85 |
Documentation
LPDA7038-11-0.5NF Technical Data Sheet
Related Products
RFI HS72 Eave/Wall (Hockey Stick) Mount "J" Pole 1.8M for Antenna Mounting
Availability
RFI LPDA7038-11-10SMA 5G LTE 11dBi LPDA Directional Antenna (700-3800 MHz); 10m SMA(M)
This item is in stock
This wide-band log periodic antenna offers high gain directional coverage and is suited to all global cellular and various other wireless network applications. The unique ruggedized diecast aluminium construction ensures optimum performance and reliability in all weather and operating environments. The LPDA antenna is to be mounted vertically with tilting capability incorporated within the clamping arrangement. Mast mounting hardware is supplied to suite pole diameters of up to 60mm
Pole not included - available to order click here
Features LPDA7038-11-10SMA:
- Wide band frequency range
- Excellent front-to-back ratio
- Easy installation using supplied hardware
- 10Mtrs RG58 Cable with SMA male connector included
The LPDA7038 antenna is to be mounted vertically with tilting capability incorporated within the clamping arrangement. Mast mounting hardware is supplied to suite pole diameters of up to 60mm and includes 0.5 metres of HDF 195 cable terminated with N Type female connector.
Specifications:
| Cable And Connector | 10 meters cable terminated with male SMA connector |
| Frequency Range | 1710 - 2170 2300 - 2700 3400 - 3800 698 - 960 |
| Frequency | 698-960 / 1710-2700 / 3400-3800 MHz |
| Wind Load (Thrust) @ 160km/h N | 160 |
| Nominal impedance | 50 |
| Power w | 10 |
| Nominal Gain Dbi | 10.8 / 11 / 2.3 |
| Dimensions | 1112 x 200 x 47mm |
| Polarisation | Vertical |
| VSWR | <1.5:1 |
| Tuned bandwidth | Full |
| Horizontal Beamwidth | 55 |
| Front Back ratio dB | 20 dB |
| Brand | RFI |
| Weight [kg] | 1.85 |
Documentation
LPDA7038-11-10SMA Technical Data Sheet
Related Products
RFI HS72 Eave/Wall (Hockey Stick) Mount "J" Pole 1.8M for Antenna Mounting
Availability
RFI 5G LTE 7.5dBi Collinear Antenna (698-3800MHz); 5m SMA(M) - White/Black 1152mm
RFI 5G LTE 7.5dBi Collinear Antenna (698-3800MHz); 5m SMA(M) - White/Black 1152mm
RFI CD8197-W 5G LTE 7.5dBi Collinear Antenna (698-3800MHz); 5m SMA(M) - White Radome Black 1152mm
KEY FEATURES:
- Patented PCB based collinear design offering the ultimate in pattern and gain stability.
- Ideal for new 5G/LTE networks with true multi-band coverage.
- High gain across all bands making it suiting fringe and rural applications.
| Packaging | Retail Hang Sell Bag |
| Whip Material | Fibreglass (White) |
| Cable And Connector | 5m RG58 (9006) Low Loss Cable Terminated with SMA(M) Connector |
| Frequency Range | 1710-2170 2300 - 2700 3400 - 3800 698 - 960 |
| Nominal impedance | 50 |
| Power w | 10 |
| Nominal Gain Dbi | 7.5 / 4.5 / 5.5 / 6.5 |
| Polarisation | Linear |
| VSWR | <2.5:1 |
| Tuned bandwidth | Full |
| Horizontal Beamwidth | Omni-directional |
| Frequency MHz | 698-960 / 1710-2170 / 2300-2700 / 3400-3800 |
| Length [mm] | 1152mm |
| Brand | RFI |
| Weight [kg] | 0.84 |
| Height [mm] | 1140 |
CHECK OUT THE RFI PRODUCT DOCUMENTATION
View the CD8100 Series Technical Data Sheet
View 8100 Series Specifications Matrix
MOUNTING BRACKET OPTIONS
Availability
RFI RFI-5M-SMA 5Mtr RG58 Cable Extension - SMA Male to SMA Female
This RFI-5M-SMA; 5Mtr extension cable is the simplest way to extend the length of your SMA terminated antenna cable to devices that use SMA male connection. (Eg Cel-Fi Go Repeaters)
Cable: RFI RG58 9006 Cellfoil 50 Ohm Coax Cable; Low Loss
Termination: SMA-104 one end SMA-186 other end
Availability
RFI A-81 ADAPTOR - SMA Female to FME Female
This adaptor is the simplest way to connect an antenna terminated with SMA connection to devices that use FME connection. (Eg carkits and cradles)
Availability
RFI Cable Extension 10Mts - SMA Male to N Male RG58 9006 Low Loss Cable
RFI Cable Extension 10Mts - SMA Male to N Male RG58 9006 Low Loss Cable
RFI 9207N-10 Cable Extension 10Mts - SMA Male to N Male RG58 9006 Low Loss cable
This 10Mtr extension cable is the simplest way to extend the length of your N (female) terminated antenna cable to devices that use SMA male connection. (Eg Cel-Fi Go Repeaters) RG58 9006 Low Loss Cable
PRODUCT DETAILS
Cable Type |
RG58 |
Cable And Connector |
10m 9006 Low Loss Cable Terminated with N Male & SMA Male Connectors |
Connector |
SMA(M) - N(M) |
Brand |
Pulse |
Component Type |
Jumper |
Related Products
RFI DAS6938-SDP150-N antenna
RFI TLA4100 antenna
Availability
RFI Cable Extension 15Mts - SMA Male to N Male RG58 9006 Low Loss Cable
RFI Cable Extension 15Mts - SMA Male to N Male RG58 9006 Low Loss Cable
RFI 9207N-15 Cable Extension 15Mts - SMA Male to N Male RG58 9006 Low Loss cable
This 15Mtr extension cable is the simplest way to extend the length of your N (female) terminated antenna cable to devices that use SMA male connection. (Eg Cel-Fi Go Repeaters) RG58 9006 Low Loss Cable
PRODUCT DETAILS
Cable Type |
RG58 |
Cable And Connector |
15m 9006 Low Loss Cable Terminated with N Male & SMA Male Connectors |
Connector |
SMA(M) - N(M) |
Brand |
Pulse |
Component Type |
Jumper |
Related Products
RFI DAS6938-SDP150-N antenna
RFI TLA4100 antenna
Availability
RFI Cable Extension 20Mts - SMA Male to N Male RG58 9006 Low Loss Cable
RFI Cable Extension 20Mts - SMA Male to N Male RG58 9006 Low Loss Cable
RFI 9207N-20 Cable Extension 20Mts - SMA Male to N Male RG58 9006 Low Loss cable
This 20Mtr extension cable is the simplest way to extend the length of your N (female) terminated antenna cable to devices that use SMA male connection. (Eg Cel-Fi Go Repeaters) RG58 9006 Low Loss Cable
PRODUCT DETAILS
Cable Type |
RG58 |
Cable And Connector |
20m 9006 Low Loss Cable Terminated with N Male & SMA Male Connectors |
Connector |
SMA(M) - N(M) |
Brand |
Pulse |
Component Type |
Jumper |
Related Products
RFI DAS6938-SDP150-N antenna
RFI TLA4100 antenna
Availability
RFI 9207N-0.5 Cable Lead 0.5Mtr - SMA Male to N Female 9006
This 0.5Mtr cable lead is the simplest way to connect your N (female) terminated antenna/accessory to devices that use SMA male connection. (Eg Cel-Fi Go Repeaters) 9006 cable
Related Products
Availability
RFI 9207D- 10 Cable Lead N (male) To N (male) Cable Lead; 10.0Mtrs 9006 Cable
Availability
RFI 9207D-5 Cable Lead N (male) To N (male) Cable Lead; 5.0Mtrs 9006 Cable
Availability
RFI Eave/Wall (Hockey Stick) Mount "J" Pole 1.8M for Antenna Mounting
RFI Eave/Wall (Hockey Stick) Mount "J" Pole 1.8M for Antenna Mounting
RFI HS72 Eave/Wall (Hockey Stick) Mount "J" Pole 1.8M for Antenna Mounting
Now back in stock
An L-shaped fascia bracket with mounting tube used to mount small yagis or dipoles. Allows the vertical mast to clear guttering.
Features:
Hot dipped galvanised finish
Right angle steel tube to fit to the roof fascia
Protrudes 180mm from fascia surface
Heavy duty construction
Other RFI mounting choices - RFI Mounting Hardware Options
Documentation
Availability
RFI SISO Low Profile Omni-Directional Ceiling Antenna (698-4000 MHz); N(F)
The DAS6940LC-SOC150-N is a compact PIM rated indoor SISO omni-directional antenna antenna covering 4G &5G Cellular bands 689-960 MHz & 1710-4000MHz. This multi-band design eliminates the need to purchase different antennas for each frequency and is ideal for all fixed in-building coverage applications.
RFI's Compact Low profile LTE DAS antenna is a high performance PIM rated DAS antenna offering Omni directional coverage solutions to suit indoor UHF & LTE coverage in a low profile aesthetic. The multi-band capability covers both UHF and 4G bands including 690-960MHz & 1710-4000MHz eliminating the need to purchase different antennas to suit different bands of operation. This range is ideal for all fixed in-building coverage applications
Features Include:
• Low Profile compact form factor
• Coverage across multiple cellular and WLAN bands
• Ideal for DAS deployment for in-building coverage solutions
• Excellent -150dBc PIM performance
• 1 x 300mm tail terminated with N type female connector
Availability
RFI LTE 11dBi LPDA Directional Enclosed Antenna (698-4000MHz); 0.3m N(F)
RFI LTE 11dBi LPDA Directional Enclosed Antenna (698-4000MHz); 0.3m N(F)
RFI LTE 11dBi LPDA Directional Enclosed Antenna (698-4000MHz); 0.3m N(F)
The LPDA7040-11-0.3NF is a high performance wide band log periodic antenna designed to operate in the LTE bands from 698 to 4000 MHz. This wideband design eliminates the need to purchase different antennas for each frequency. This simplifies installations since the same antenna can be used for a wide array of wireless applications where wide coverage is desired. The brass & aluminium internal components of this antenna are enclosed within a UV-stable white ABS radome for all-weather operation and is supplied with a tilt and swivel mast mount kit.
Features:
- Broad operating frequency range
- Compact design
- IP65
- Urban and rural areas - Poor data signal reception (indoor or outdoor)
- Slow data transmission connection
- Unstable connection
- Increase system transmission reliability
- LTE fringe areas (close to an LTE area but just out of reach)
- Network operator flexibility - as the antennas is wideband a new antenna is not needed per network operator
- Works on most networks.
Also available with a 10Mtr RG58 cable terminated with SMA male connector - click here
| Cable And Connector | 0.3 m RG141 cable terminated with N type female connector |
| Connector | N(F) |
| Frequency Range | 1710 - 2170 2300 - 2700 3300 - 3800 698 - 960 |
| Power w | 50 |
| Nominal Gain Dbi | 9.5 / 11.0 / 11.5 |
| Dimensions | 440 x 205 x 60mm |
| Polarisation | Linear |
| VSWR | <2.0:1 |
| Mounting area | Up to 52mm diameter pole |
| Tuned bandwidth | Full |
| Passive IM 3rd Order (2x20W) dBc | -153 |
| Horizontal Beamwidth | 90 / 75 / 54 |
| Front Back ratio dB | 15 |
| Frequency MHz | 698-960 / 1710-2700 / 3300-4000 |
| Brand | RFI |
| Weight [kg] | 1 |
Documentation
View LPDA7040-11-0.3NF data sheet
What’s in the box
The LPDA antenna is to be mounted vertically with tilting capability incorporated within the clamping arrangement. Mast mounting hardware is supplied to suit pole diameters of up to 52mm. (Mounting pole not included)
1 x LPDA with 0.3 metres cable terminated with N Type female connector
1 x Antenna L bracket
2 x Mounting plates
2 x M6 U-bolts (including: 4 x M6 Nuts 4 x Flat washers & 4 x Spring washers)
Related Products
Also available with a 10Mtr RG58 cable terminated with SMA male connector - click here
Availability
LPDA7040-11-10SMA LTE 11dBi LPDA Directional Enclosed Antenna (698-4000MHz); includes 10m cable RG58 / SMA male.
The RFI LPDA7040-11-10SMA is a high performance wide band log periodic antenna designed to operate in the LTE bands from 698 to 4000 MHz. This wideband design eliminates the need to purchase different antennas for each frequency. This simplifies installations since the same antenna can be used for a wide array of wireless applications where wide coverage is desired. The brass & aluminium internal components of this antenna are enclosed within a UV-stable white ABS radome for all-weather operation and is supplied with a tilt and swivel mast mount kit.
LPDA7040-11-10SMA:
- Broad operating frequency range
- Compact design
- IP65
- Increase system transmission reliability
- LTE fringe areas (close to an LTE area but just out of reach)
- Network operator flexibility - as the antennas is wideband a new antenna is not needed per network operator
- Works on most networks
- 10mtr RG58 cable with SMA (m) connection included
| Cable And Connector | 0.3 m RG141 cable terminated with N type female connector |
| Connector | N(F) |
| Frequency Range | 1710 - 2170 2300 - 2700 3300 - 3800 698 - 960 |
| Power w | 50 |
| Nominal Gain Dbi | 9.5 / 11.0 / 11.5 |
| Dimensions | 440 x 205 x 60mm |
| Polarisation | Linear |
| VSWR | <2.0:1 |
| Mounting area | Up to 52mm diameter pole |
| Tuned bandwidth | Full |
| Passive IM 3rd Order (2x20W) dBc | -153 |
| Horizontal Beamwidth | 90 / 75 / 54 |
| Front Back ratio dB | 15 |
| Frequency MHz | 698-960 / 1710-2700 / 3300-4000 |
| Brand | RFI |
| Weight [kg] | 1 |
Documentation
View LPDA7040-11-0.3NF data sheet
What’s in the box
The LPDA antenna is to be mounted vertically with tilting capability incorporated within the clamping arrangement. Mast mounting hardware is supplied to suit pole diameters of up to 52mm. (Mounting pole not included)
1 x LPDA with 0.3 metres cable terminated with N Type female connector
1 x Antenna L bracket
2 x Mounting plates
2 x M6 U-bolts (including: 4 x M6 Nuts 4 x Flat washers & 4 x Spring washers)
1 x 10Mtrs RG58 Cable with SMA male connector
Availability
